Includes:

Matrix Nexus 2 Control

Auto Parts Catcher

Chip Conveyor

213 PSI High-Power Coolant

Automatic Tool Eye

12” Chuck Head One

10” Chuck Head Two

Factory Supplied Tooling Package

All Available Manuals

NOTE: Barfeeder not included.  Available in late August / early September

Specifications:

Swing: 32.68"

Turning Diameter: 16.6"

Center Distance: 62.2"

Chuck Size: 12"

Bar Capacity: 4.05"

X Axis Travel: 10.75"

Y Axis Travel: 6.90"

Z Axis Travel: 62.25"

C Axis Index: 0.001

Main Spindle Speed: 3,500 rpm

Main Motor: 40 hp

Live Tooling Speed: 4,000 rpm

Sub Spindle Chuck: 10"

Second Spindle Speed 4,000 RPM

Sub Spindle Bar Capacity: 2.55"

Sub Spindle Motor (HP): 25

Turret Capacity: 12 Station
